ITACA KC (high efficiency)

Wall-hung condensing boiler with instantaneous production of DHW

Can be matched to outdoor installation kit

Compatible with SPOT smart thermostat

PLUS

Ambient temperature probe supplied as standard
Modulation ratio 1:9
Condensation also in DHW operation thanks to the thermally insulated 26-plate DHW heat exchanger
Management of one heating zone with ambient temperature probe and two zones with zone kit
Double filling system: automatic and manual
High domestic hot water production, more power during DHW operation
Multifunction relay for connection to systems with zone valves or to solar plant or to remote alarm signal

Request Info

BIM

ITACA KC

Description
Technical specifications
Documentation

FEATURES

Controls to manage two different types of solar thermal systems fitted as standard
Thermopolymer-covered stainless steel heat exchanger
Heating expansion vessel - 10 litres
Thermoregulation with external probe (optional)
DHW “Comfort” function: ★★★
High-efficiency modulating circulation pump with built-in air purging device

Models	Alimentation	Rated heat input [kW]	Dimensions L x H x P [mm]	Gross weight [Kg]
ITACA KC 12	METHANE PROPANE	12,0	420x750x315	35,5
ITACA KC 24	METHANE PROPANE	23,7	420x750x315	37,5
ITACA KC 28	METHANE PROPANE	26,4	420x750x315	40,5
ITACA KC 32	METHANE PROPANE	30,4	420x750x315	41,5

Technical instructions
- Downloads
  3.57 MB

  IST ITACA CONDENSING ERP - EN
- Downloads
  13.27 MB

  IST ITACA CONDENSING - ERP - H2 READY
Energy Label
- Downloads
  2.25 MB

  ITACA KC 32
- Downloads
  2.54 MB

  ITACA KC 24 - EU ONLY
- Downloads
  2.18 MB

  ITACA KC 28 - EU ONLY
Catalogues
- Downloads
  16.17 MB

  CATALOGUE BOILERS ERP GAR - EN
- Downloads
  14.62 MB

  CATALOGUE BOILERS - EXTRA EU - EN
Declaration of conformity
- Downloads
  0.2 MB

  ITACA CONDENSING
