Fondital aluminium radiator, pre-set with bottom connection kit, becomes the ideal replacement of old steel-plate radiator systems.

Pure White RAL 9010

PLUS

  • Optimal weight-to-heat output ratio
  • Modular: perfect for any space
  • No welds, so no problems with burrs
  • 100% MADE IN ITALY
  • Improved heat exchange = high performance, low consumption

By purchasing the special right or left element and the most suitable valve for your system, you can obtain a radiator with connections on the right or left side of the floor or wall.

RH-LH VALVE BOTTOM TO WALL CONNECTION KIT RH-LH VALVE BOTTOM TO FLOOR CONNECTION KIT RH-LH VALVE BOTTOM CONNECTION KIT WITH BYPASS FOR SINGLE-PIPE SYSTEMS




All models are guaranteed 10 years from installation date on manufacturing faults, provided that the installation has been performed in compliance with the current norms and respecting the instructions relating to the installation, the correct use and the correct maintenance.

Models Depth (C) mm Height (B) mm Centre distance (A) mm Length (D) mm Connection diameters [inches] Water capacity [litres/sect.] Heat output W/sect. (ΔT 30) Heat output W/sect. (ΔT 50) Exponent n Coefficient [Km]
350/100 97 407 350 80 G1 0,21 47,3 91,5 1,2910 0,5865
500/100 97 556 500 80 G1 0,26 59,5 114,5 1,2813 0,7588
600/100 97 657 600 80 G1 0,29 67,8 131,5 1,2957 0,8270

Maximum working pressure: 1600 kpa (16 bar); Maximum working temperature: 120 °C
Characteristic equation of the model Ф=Кm ΔТn
The thermal efficiency values shown comply with the European Standard EN 442-1:2014 and are certified by the MRT Lab of the Milan Polytechnic, notified body №1695.
